Air-to-air heat pump Daikin Stylish OH5
A wall-mounted model with a unique design for heating and cooling
Heating area
Cooling area
Color
1 979,00 €
1 622,13 € + VAT
Available in-store
Delivery time when ordering from the online store 1-3 business days
427,00 €
Product code: FTXTA30CW / RXTA30C
- Operates effectively up to -30°C outdoor temperature
- Max. heating capacity at -15°C outdoor temperature: 4.8 kW
- Max. heating capacity at -20°C outdoor temperature: 4.3 kW
- Optimized airflow with Coanda effect
- Daikin Flash Streamer air purifier/ionizer
- Multi-zone room temperature sensing sensor
- Low noise level, 19 dB(A)
- Integrated WiFi controller
- Fireplace function
- R32 Refrigerant
Connection to the indoor unit requires an EKRS21 adapter. The WiFi function must be deactivated.
Technical specifications
| Manufacturer | Daikin | Daikin |
|---|---|---|
| Model | Stylish | Stylish |
| Heated area | up to 80 m² | up to 80 m² |
| Cooled area | up to 35 m² | up to 35 m² |
| Product code | FTXTA30CW / RXTA30C | FTXTA30CB / RXTA30C |
| Product type | Air-to-air heat pump | Air-to-air heat pump |
| Heating capacity (Min./Nom./Max.) | 0.8/3.2/7.1 kW | 0.8/3.2/7.1 kW |
| Cooling capacity (Min./Nom./Max.) | 1.2/3.0/4.6 kW | 1.2/3.0/4.6 kW |
| Energy efficiency class | A+++/A+ | A+++/A+ |
| Warranty | 2 years | 2 years |
| Estonian language menu | Yes | Yes |
| Wi-Fi smart remote control | Yes | Yes |
| Color | white | matte black |
| Operating limit (Cooling) | -10 ~ 46 °C | -10 ~ 46 °C |
| Operating limit (Heating) | -30 ~ 24 °C | -30 ~ 24 °C |
| Refrigerant | R32 | R32 |
| Pipe size (Liquid/Gas) | 6.35/ 9.5 mm | 6.35/ 9.5 mm |
| Maximum height difference | 15 m | 15 m |
| Maximum pipe length | 20 m | 20 m |
| Power supply voltage | 220-240/1/50 V/Ph/Hz | 220-240/1/50 V/Ph/Hz |
| Protection circuit breaker | 16 A | 16 A |
| Nominal heating capacity | 3.2 kW | 3.2 kW |
| Nominal cooling capacity | 3.0 kW | 3.0 kW |
| SCOP (Warm/medium/cold climate) | 5.18-4.14 | 5.18-4.14 |
| SEER | 8.75 | 8.75 |
| Indoor unit | ||
| Indoor unit weight | 12 kg | 12 kg |
| Indoor unit dimensions (width x height x depth) | 798x295x189 mm | 798x295x189 mm |
| Indoor unit noise level | 20/25/32/43 ~ 19/24/31/41 dB(A) | 20/25/32/43 ~ 19/24/31/41 dB(A) |
| Outdoor unit | ||
| Outdoor unit weight | 42 kg | 42 kg |
| Outdoor unit dimensions (width x height x depth) | 930x605x376 mm | 930x605x376 mm |
| Outdoor noise level | 48 dB(A) | 48 dB(A) |
